Toro Workman UTX 4 Passenger Gasoline
Model: 08101
Toro Workman UTX 4 Passenger Gasoline
Model: 08101
The Workman UTX is a straight-forward, no-nonsense, 4-wheel drive utility vehicle built to stand up to the toughest tests without compromising performance. With standard commercial-grade components, the highest payload in its class and a proprietary speed control system, its designed for the rigors of a long work week, not a few hours of recreation on the weekends. The Workman UTX has the muscle to blast through snow drifts while still maintaining the ability to regulate speed and sound in sensitive areas. To raise the standard further, every Workman UTX features an integrated plow mount, power steering, turn signals, brake lights, and a spray-on bed liner.
- A proprietary speed control system ensures your crew uses the right speed for the job and that the power used matches the task at hand.
- A ton (2,000 lbs. / 907 kg) of towing, 25% more cargo capacity than competitors and two standard 2” (5 cm) receivers (front and rear) gives the Workman UTX the means to tackle any job.
- With a rock-solid, high-strength steel frame, integrated plow mount, Selectable 4WD with front and rear differential locks and oversized shocks, bearings and bushings the Workman UTX is up to any challenge.
- The Workman UTX is made to work in multiple environments. Its road ready with standard LED headlights, turn signals, hazards and brake lights and built to handle snow and ice like a BOSS®.
Precision Control
A proprietary speed control system ensures your crew uses the right speed for the job and that the power used matches the task at hand.
Capable Of Doing Any Job
A ton (2,000 lbs. / 907 kg) of towing, 25% more cargo capacity than competitors and two standard 2” (5 cm) receivers (front and rear) gives the Workman UTX the means to tackle any job.
Commercial-Grade Tough
With a rock-solid, high-strength steel frame, integrated plow mount, Selectable 4WD with front and rear differential locks and oversized shocks, bearings and bushings the Workman UTX is up to any challenge.
Versatile Performance
The Workman UTX is made to work in multiple environments. Its road ready with standard LED headlights, turn signals, hazards and brake lights and built to handle snow and ice like a BOSS®.
All-Day & All-Season Comfort
2 or 4-passenger models make sure you have the room for you and your crew and a climate controlled cab keeps them comfortable in any conditions.
Specifications
| Air Filter |
Remote mounted, heavy duty 2-stage air cleaner with evacuator valve
|
| Alternator |
85 Amps @ 4800 RPM
|
| Battery |
12V
|
| Brakes - Front |
Hydraulic Disc
|
| Brakes - Rear |
Hydraulic disc
|
| Cab Unit |
No |
| Cargo Bed |
Yes |
| Cargo Bed Capacity |
1,000 lbs
|
| Cargo Bed Dimensions |
Loading Dimensions: Total 56” x 44.5” x 11” (with standard spray-in bedliner)
Total Volume: 17.05 ft3 |
| Controls |
Headlights, Hazards, Turn signal, Horn, Cruise Control, 4WD, Differential Locks, Gear Selector, Steering Wheel, Brake, Accelerator.
|
| Cooling System |
Liquid Cooled
|
| Crated Model |
No
|
| Differential Lock |
Selectable Electronic Locking, Front and Rear
|
| Displacement |
998 cc
|
| Drivetrain |
Gas |
| Frame |
High-strength steel with E-coat primer and powder top coat
|
| Fuel / Power Source |
Gasoline |
| Fuel Capacity |
8.5 gallons
|
| Fuel Filter |
In-tank 10 micron filter sock
|
| Fuel Pump |
12V Remote Electronic Pump
|
| Gauges/Instrumentation |
Digital Display with system/engine diagnostics, speed, rpm, 4WD and differential lock indicator, fuel level, coolant temperature, hour meter, seat belt indicator, speed limited/cruise control indicator, turn signal/hazard/headlight indicators
|
| Ground Clearance |
9"
|
| Ground Speed - Forward |
0-45 mph
|
| Ground Speed - Reverse |
0-15 mph
|
| Height |
79"
|
| High Speed Lockout |
Top speed: 45 mph with ability to limit down to 5 mph
|
| Horn |
Standard |
| Lights |
Standard LED Headlights
|
| Oil Capacity with Filter |
SAE 15W-40 (3.0 qt)
|
| Optional Accessories |
Canopy, glass windshield with wiper and washer, polycarbonate windshield, doors, rear panel, heat, air conditioning, overhead console, under seat storage, work lights, beacon, electric bed lift, back up alarm, 12v power source, side mirrors, rearview mirror, bed raking, 27" tires, draw bar, supervisor key, Boss plows and Boss salt spreader.
|
| Overall Width |
60.5"
|
| Parking/Service Brakes |
Integrated
|
| Power Rating |
37.1 hp at 3850 RPM
|
| Power Steering |
Yes
|
| Power Train (Engine Description) |
37.1 HP, Inline 4-cylinder, Toro
|
| Product Length |
123.5"
|
| Rear Draw Bar |
Optional |
| Roll-Over Protection (ROPS) |
Standard
|
| Starting |
Key Start
|
| Suspension - Front |
Fully independent MacPherson Strut with adjustable coil over shocks
|
| Suspension - Rear |
Fully independent Dual A-Arm with adjustable coil over shocks
|
| Suspension Travel - Front |
6"
|
| Suspension Travel - Rear |
5"
|
| Tires - Front |
25” x 9” – 12”, Turf Tire on steel wheel
|
| Tires - Rear |
25” x 11” – 12”, Turf Tire on steel wheel
|
| Total Vehicle Capacity |
2,050 lbs
|
| Towing Capacity |
2,000 lbs
|
| Traction Drive |
Park, Reverse, Neutral, High, Low transaxle
|
| Traction Drive (System) |
4WD |
| Transmission |
Continuously Variable Transmission (CVT) with clutch enclosure
|
| Transport Width |
60.5"
|
| Vehicle Configuration |
Standard |
| Vehicle Type |
Crew
|
| Weight |
1950lbs
|
| Wheelbase |
80"
|
