Toro ProCore® SR70-S Turf Aerator

Model: 09934
Toro

Toro ProCore® SR70-S Turf Aerator

Model: 09934
Toro

Deep-tine aerification relieves soil compaction at lower soil levels than typical aerification. The tines fracture the soil creating channels through the root zone allowing oxygen, water and critical nutrients to penetrate deep into the soil profile.

The crankshaft, tine arms and frame are perfectly aligned allowing for superior performance and long life. With its fast, efficient performance and innovative design, the deep-tine aerators are able to run smoothly at all depths, relieving pressure-packed soil with superior hole quality. There are many coring and solid tines available to cover a wide variety of cultivation practices. All of the deep-tine models utilize a standard 3-point hitch hook-up and are powered from the PTO.

The leverage of the aerator allows the weight to be placed directly over the point of impact, enabling lightweight units to do heavyweight jobs while reducing shock and wear and tear on the machines. There are multiple positions available to adjust the soil fracturing movement of the tines. This allows you to adjust and control this motion to your desired application. These robust machines are capable of withstanding extreme aeration conditions. The heavy-duty design includes an oversized gearbox, heavy-duty bearings, crank arms and chains, allowing you to operate in the toughest conditions.

Fleet Finance & Leasing Options Talk to us today 0800 807 333

Features

Precision Design

The crankshaft, tine arms and frame are perfectly aligned allowing for superior performance and long life. With its fast, efficient performance and innovative design, the deep-tine aerators are able to run smoothly at all depths, relieving pressure-packed soil with superior hole quality.

Coring & Solid Tines

There are many coring and solid tines available to cover a wide variety of cultivation practices.

Easy Hook-Up & Operation

All of the deep-tine models utilize a standard 3-point hitch hook-up and are powered from the PTO.

Superior Punching Power

The leverage of the aerator allows the weight to be placed directly over the point of impact, enabling lightweight units to do heavyweight jobs while reducing shock and wear and tear on the machines.

Adjustable Soil Fracturing Capabilities

There are multiple positions available to adjust the soil fracturing movement of the tines. This allows you to adjust and control this motion to your desired application.

Heavy-Duty Design

These robust machines are capable of withstanding extreme aeration conditions. The heavy-duty design includes an oversized gearbox, heavy-duty bearings, crank arms and chains, allowing you to operate in the toughest conditions.

Specifications

Aeration Type Deep
Forward Hole Spacing 2.5" - 4" (64 - 102 mm)
Lift System Standard 3-point.
Maximum Operating Depth (Working Depth) 1" - 10" (25 - 250 mm)
Maximum PTO Speed 400 - 500 rpm
Number of Tine Heads 8
Operating Speed 1.5 - 2.5 mph (2.41 - 4.02 kph)
Operating Width (Working Width) 73" (1.85 m)
Optional Accessories Rear Roller Kit (09953)
Productivity 48,000 sq. ft. / hour (4,460 sq. m / hour)
Recommended Tow Vehicle Requirement 25 - 35 hp (18.6 - 26.1 kW) with minimum 1,800 lb. (817 kg) lift capacity
Weight 1,655 lbs. (750 kg)
