Toro ProCore 864 Aerator

Fleet Finance & Leasing Options Avaliable
Talk to us today 0800 807 333

The TORO ProCore 864 is one of the newest additions to our highly innovative aeration product line. Featuring the same ground-breaking technology that allowed the ProCore 648 to revolutionize greens aeration, combined with an improved platform designed for large-area applications. The most productive and durable large area aerators available today.

  • 64 inch (162.6 cm) aeration swath
  • Precision-balanced coring heads deliver
    remarkably smooth operation
  • Impact resistant system withstands the most
    rugged conditions
  • RotaLinkTM delivers superior hole quality
  • Oversized gear box for robust operation
View Larger
Belt Drive Aeration Head

Kevlar reinforced belt drives provide smooth, quiet operation along with robust durability. This leads to increased operator comfort and a more enjoyable aeration experience.

View Larger
Depth Control Mechanism

The depth control mechanism provides a quick and easy method for changing hole depth. The depth setting has a high gear ratio making changing depth a quick and effortless task.

View Larger
High Quality Holes at Consistent Depths

The RotaLink™ tine guide mechanism ensures tines remain vertical as they enter and exit the ground. This produces consistently clean holes for better looking turf and easier top dressing fill if required. The ProCore® tine placement is close to the roller, keeping them at a consistent depth as the operator travels over undulations.

View Larger
Impact Resistance System

The compression springs combined with the independent coring head provide positive down pressure to ensure proper hole depth in the downward direction and provide a dampening affect in the upward direction when a large object is impacted during aeration.

View Larger
Increased Productivity

The efficient 64″ (162 cm) and 98″ (249 cm) aeration swath deliver maximum productivity for a broad range of forward hole spaces.

View Larger
Operator Comfort and Ease of Use

The precision balancing weights eliminates hopping, rocking, and uncomfortable vibration for less operator fatigue and a more productive and efficient aeration experience. It allows the aerator to run in the up position and simplifies operation and increases efficiency in turn around.

View Larger
Oversized Gear Box

The oversized gear box provides improved capacity and durability for the toughest turf conditions.

View Larger
Precision Balanced Drive System

The ProCore® drive has precision balancing weights and each coring head is modeled after a 6-cylinder engine with precision balancing. This configuration eliminates hopping, rocking, and uncomforting vibration. This leads to less operator fatigue and a more productive and efficient aeration experience.

View Larger
Reduced Simplified Maintenance

Easy access to service components and minimal grease points result in less maintenance and less time performing maintenance tasks. This leads to higher machine and operator productivity and allows technicians to be more efficient.

View Larger
RotaLink™ Tine Guide Mechanism

A linked mechanism that guides the tine actuation path and ensures they remain vertical as they enter and exit the ground. This produces consistent, clean holes for better looking turf and improved top dressing fill.


The same ground-breaking technology that allowed the ProCore 648 to revolutionize greens aeration is available for large-area applications. The precision-balanced coring heads run smoothly, even in the raised position with the PTO engaged. This will save you valuable time in turn arounds and avoiding ground obstacles. The ProCore 864 delivers exceptional aeration and productivity in an easy to use, robust design.

  • Aerating Depth: Up to 12.7 cm (5 inches)
  • Aerating Width: 162.6 cm (64 inches)
  • Height: 97.8 cm (38.5″)
  • Length: 88.9 cm (35″)
  • Lift System: 3-point Category 1 or 2
  • Tine Heads: 8
  • Tractor PTO: 540 RPM
  • Tractor Size: 30 hp (22.4 kw) @ PTO minimum, 35 hp (26.1 kw) @ PTO recommended
  • Weight: 714.4 kg (1,575 lbs.)
  • Width: 170.2 cm (67″)
